Hooker
Product Details
🔧
Vehicle Compatibility
Fits Hooker Small Block Chevrolet Exhaust Manifolds.
Please refer to manufacturer specifications for complete compatibility information.
⭐
Key Features
Small Block Chevy Universal Exhaust Manifolds, 2.5" collector, Silver Ceramic Finish
- A smoother, cleaner appearance compared to original exhaust manifolds, while maintaining a factory style look and feel
- Made from high silicon-molybdenum ductile iron for high temperature strength plus resistance to oxidation and cracking
- Designed with a larger 1 5/8� cross-sectional area and 2 ½� outlets for better air flow and increased performance
- Designed for rectangular port heads
- Accommodates standard straight and Vortec straight plug head designs for better application coverage
- Includes weld-on flanges for easier downpipe pipe installation (custom downpipe required)
- Available in natural cast iron or ceramic coated finishes (silver, black and titanium)
- Includes mounting hardware and gaskets for inlet and outlet flanges
🎬
Product Videos
No videos available for this product.
📋
Product Specifications
Bolt Size
3/8-16 x 3/4
Brand
Hooker
California Proposition 65 Required
Yes
CARB (California) Compliant
No
Collector Diameter
2.50 inch
Engine
Chevrolet Small Block Gen I
Exhaust Port Shape
Rectangle
Header Style
Manifold
Menu
Exhaust Manifolds
Part Type
Exhaust Manifold
Primary Tube Diameter
1-5/8 inch IN
Product Type
Manifold
📦
Package Contents
Kit includes all necessary components. Please refer to manufacturer specifications for detailed package contents.
