PROMAG PWR GRID TIMING CONT...
Get notified when this item is back in stock
Press & drag to view
MSD
Product Details
🔧
Vehicle Compatibility
Fits PROMAG PWR GRID TIMING CONTROL TOP - MSD Dual Channel Power Grid Timing Controller.
Please refer to manufacturer specifications for complete compatibility information.
⭐
Key Features
MSD Dual Channel Power Grid Timing Controller
The Dual Channel Power Grid incorporates a high-speed 32-bit microprocessor and PC software, called MSD View via a USB BluetoothTM wireless. It includes a high-speed data acquisition recording engine RPM, timing, dual Tach signal, launch/WOT with sample rates of 100 samples per second or 10 milliseconds. _x000D_ _x000D_ The MSD View software will program timing curves with up to 30 points at 1.0 increments down to 0.01 second intervals. Multiple timing curves can be overlayed to choose the right one at the last minute. Other unique programs include a throttle lift timing retard, throttle inhibit timing retard, and an auto pickup signal selector. This means that in the case of a crank trigger pickup failure, it will trigger the dead channel running magnetos seamlessly._x000D_ _x000D_ The MSD View software includes a virtual dashboard that can be configured to display engine RPM, Timing, Timing Retard, WOT, Timing Reset, Crank Trigger inputs, and Output Triggers. Includes a CAN-Bus connection sending the recording to the RacePak data logger.
The Dual Channel Power Grid incorporates a high-speed 32-bit microprocessor and PC software, called MSD View via a USB BluetoothTM wireless. It includes a high-speed data acquisition recording engine RPM, timing, dual Tach signal, launch/WOT with sample rates of 100 samples per second or 10 milliseconds. _x000D_ _x000D_ The MSD View software will program timing curves with up to 30 points at 1.0 increments down to 0.01 second intervals. Multiple timing curves can be overlayed to choose the right one at the last minute. Other unique programs include a throttle lift timing retard, throttle inhibit timing retard, and an auto pickup signal selector. This means that in the case of a crank trigger pickup failure, it will trigger the dead channel running magnetos seamlessly._x000D_ _x000D_ The MSD View software includes a virtual dashboard that can be configured to display engine RPM, Timing, Timing Retard, WOT, Timing Reset, Crank Trigger inputs, and Output Triggers. Includes a CAN-Bus connection sending the recording to the RacePak data logger.
🎬
Product Videos
No videos available for this product.
📋
Product Specifications
Brand
MSD
Category
Ignition
Color
Grey
Connector Gender
Male Female
Connector Quantity
6
Emission Code
4
Grade Type
Race
Height
6.3
Ignition Type
Performance
Length
7.6
Mount Type
Surface Mount
Mounting Hardware Included
Yes
Product Type
Power Grid Controller
Sub Category
Control Modules
Terminal Gender
Male Female
Terminal Quantity
27
Warning
California Proposition 65
Warranty
Manufacturer's Limited 1 Year Warranty
Width
7.5
📦
Package Contents
Kit includes all necessary components. Please refer to manufacturer specifications for detailed package contents.
