Holley EFI
Product Details
🔧
Vehicle Compatibility
Fits HP UNIVERSAL RETROFIT KIT FOR 4500 INTAK - HP EFI Universal MPI Retrofit Kits.
Please refer to manufacturer specifications for complete compatibility information.
⭐
Key Features
HP EFI Universal MPI Retrofit Kit, 4500ž carburetor style intake manifolds
- Turbo boost control
- Integrated Water/Methanol injection control
- Self-tuning fuel table strategy greatly simplifies tuning process
- Individual cylinder fuel and spark control allows you to unlock your engines potential
- Works with 4, 6, 8 cylinder engines
- Unique lb/hr based fueling strategy greatly simplifies and commonizes tuning
- Advanced idle, closed loop, and enrichment strategies allow for very stable operation
- NEW V2 SOFTWARE FEATURES
- ECU is fully potted and can be mounted in the engine compartment or interior
- “Quick Start� ignition and fueling strategy for LS x Engines
- Data Logger. Scalable axes, Smoothing, Multiple graph view ability, Pre-defined notes fields and many more
- Sealed automotive and marine grade connectors
- Allows for use of common OEM sensors as well as customer sensor calibration input
- Strip Chart Real-Time Data Viewer
- Ignition Plug and Play with GM 24x and 58x LSx engines, GM HEI, Ford TFI, magnetic and hall effect trigger, and other ignition systems. New Plug and Play applications in process.
- Integrated Boost Control - Boost vs Time, Boost vs Gear (Time or RPM), Boost vs RPM, Boost vs Speed, Launch control. Boost launch builder, Over-boost safeties, Boost scramble
- Custom settings can be configured to allow many other applications
- Traction Control - Power reduction via timing, nitrous percentage or boost (Requires Davis Technologies Holley Module)
- 1-5 Bar MAP sensor capability
- “Quick Start� fueling for all engines
- Option for VE based fueling strategy
- Two channel knock control sensor Inputs for both one or two wire knock sensors
- Dedicated fuel and oil pressure inputs
- Fuel Map and Learn Function Smoothing
- Configurable User Password Protection
- Controls both stepper and PWM Idle Air Control (IAC) motors
- Fully Configurable lap top Gauge Panel
- Speed density, Alpha-N, or combination fueling strategies
- 4 Programmable high or low Pulse Width Modulated (PWM) outputs and 4 fully configurable inputs can be configured for use
- FEATURES
- 4 Stage nitrous oxide control
- Optional 5.7� full-color touchscreen LCD allows easy on-the-fly tuning,data-logging or can be used as an easy to see graphical gauge panel
- Eight sequentially driven 8:2 peak and hold injector drivers, capable of driving up to 16 low or high impedance injectors as a standard feature. Multiple staged injector strategies
- Fully featured nitrous control eliminates the need for a separate nitrous controller device
- Can be configured “Wet� or “Dry� with closed loop feedback
- Eight channel Distributorless Ignition (DIS)outputs capable of directly driving “Smart� ignition coils or Holley DIS coils. Will drive 2 wire coils with the addition of PN 554-112 high current coil driver module
- Plug and Play control of factory GM 24x and 58x LSx engines
- Progressive control based on time, RPM, or boost, requires part # 554-111
- Integrated single channel wide band oxygen sensor control. Works with NTK or Bosch sensors
- Lean or rich safety cutoff
- Full timing retard/control configurability per stage based on RPM or time
- Internal data-logging standard with a huge 2GB of memory
- 4 Stage progressive nitrous control
- Uses Holley Water/Meth solenoids specially designed and calibrated for use with this EFI system to allow the user to enter Water/Meth flow as a percentage of fuel injector flow for Water/Meth tu
📋
Product Specifications
Accelerometer Support
Yes
Brand
Holley EFI
CAN-BUS Support
Yes
Coil Per Cylinder Ignition Support
Yes
Datalogging Support
Yes
Distributor Included
No
e85 Support
No
EGT Support
Yes
Forced Induction Support
Yes
Fuel Filter Included
No
Fuel Hose Included
No
Fuel Injectors Included
No
Fuel Pressure Regulator Included
No
Fuel Pump Included
No
Grade Type
Performance
Idle Air Control Motor Included
No
Individual Cylinder Fuel Corrections
No
Intake Manifold Included
No
Knock Retard Support
Yes
Mounting Hardware Included
Yes
Part Type
Fuel Injection System
Product Type
Universal Multi Port
Self-Tuning
Yes
Throttle Position Sensor Included
Yes
User-Tuneable
Yes
📦
Package Contents
Kit includes all necessary components. Please refer to manufacturer specifications for detailed package contents.
