Product Details
Compatibility
Fits Single Plane EFI 4500 Split-Design Race Intake Manifold- GM LS1/LS2/LS6.
Please refer to manufacturer specifications for complete compatibility information.
Product Specifications
Barrels
4
Basic Operating RPM Range
2500-7500 R3
Brand
Holley
Carburetor Flange
Dominator/4500
Carburetor Studs Included
No
Construction
Cast
EGR Port
No
Engine
GM LS1/LS2/LS6
Flange Style
4500
Fuel Injectors Included
No
Fuel Rail(s) Included
No
Fuel System Type
EFI
Gasket Or Seal Included
No
Grade Type
Performance
Intake Port Gasket(s) Included
No
Manifold Type
Split Single Plane
Nitrous Bung(s) Included
No
Part Type
Engine Intake Manifold
Product Type
Intake Manifold
Removable Runners
No
RPM Power Band
2500-7000
Single Or Dual Plane Type
Single Plane
Throttle Body Included
No
Warranty
Manufacturer's Limited 90 Day Warranty
Product Description
Key Features
Split-Design Race Intake Manifold- GM LS1/LS2/LS6 Cast Finish with Fuel Rails
- Maximum performance 4500 Dominator flange race design with hood clearance consideration
- Lighter than other split race intakes
- Split feature making porting efforts easy!
- 33 to 50% the price of other split race intakes
- Captured O-ring seals at head ports and plenum split
- Vacuum Port options include (2) 1/8, (1) 1/4, and (1) 3/8, NPT ports at the carb flange
- Two versions available: EFI type - Billet Fuel Rails and rail mounting hardware included, or Carbureted / Sniper EFI 4500 TBI style
Package Contents
Kit includes all necessary components. Please refer to manufacturer specifications for detailed package contents.
