Holley EFIPart 522-228xfmMade in CN
Product Details
⭐
Key Features
Designed for use in installs with a 38mm distance between the o-ring seats on the fuel rail and intake manifold (commonly referred to as an "LS3 style" injector), this injector features a USCAR connector and 14mm o-rings on both ends. It is an ideal fit f
Terminator X fuel injectors are dynamic flow matched within 1%, resulting in extremely precision and consistent injector characteristics. These injectors provide excellent linearity with no discernible "bounce" at low pulse widths as commonly found in other injectors. With a wide variety of fuel flow offerings from 42 lb./hr. to 220 lb./hr. (441 cc/m to 2310 cc/m), you're sure to find an injector that matches your non-emissions controlled application. These high quality fuel injectors can also be used with any ECU that utilize high impedance fuel injector drivers.
PICO/EV6 Style - High Impedance - Flow Matched
- PICO/EV6 style performance injectors
- Dynamic flow matched within 1%
- High impedance for use with saturated drivers
- 220lb/hr injectors rated at 43 PSI base pressure
- Rated injector flow from 42lb/hr to 120lb/hr for a wide array of applications (At 60 PSI base pressure, 220lb/hr injectors rated at 43 PSI base pressure)
- 40mm o-ring to o-ring length
- Injector off time provided in Holley EFI software
📖
About this product
PICO/EV6 Style - High Impedance - Flow Matched
📋
Product Specifications
Automotive Item Grade
Performance
Body Diameter
0.65
Body Length
1.85"
Body Style
EV6
Brand
Holley EFI
California Proposition 65 Chemical Name
1
California Proposition 65 Required
Yes
Category
Air and Fuel Delivery
Connector Series
EV6
Connector Series
USCAR - EV6
Country
CN
Emission Code
3
Emission Code
4
Flow Matched
Yes
Fuel Type
E-85
Grade Type
Performance
HTS Code
8409915085
Impedance
High (12.2 Ohm)
O-Ring To O-Ring
1.421
Part Type
Fuel Injector Kit
Part Type
Fuel Injector Set
Product Type
Fuel Injector
Prop 65 Yes/No
Yes
Qty
8
Rated Injector Flow
220 lb/hr
Sub Category
Fuel Injection System and Related Components
Terminal Quantity
1
Universal Or Specific Fit
Universal
Warning
California Proposition 65
Warranty
Manufacturer's Limited 90 Day Warranty
🛡️
Warranty & Compliance
Warranty
Manufacturer's Limited 90 Day Warranty
Country of Origin
CN
⚠ Prop 65 Warning
Yes
1
Emissions Code
4
HS Code
8409915085
📐
Dimensions & Shipping
Product Dimensions
8.8 × 5.4 × 2.35 in
Shipping Dimensions
8.8 × 5.4 × 2.35 in
Weight
336 g (0.34 kg)
